Example 1: Two arm | Fixed design | Continuous

example-1.Rmd

This example simulates a Phase II/III parallel-group trial evaluating a new treatment against placebo on a continuous primary endpoint (e.g., a biomarker score or symptom scale). With 100 subjects randomised 1:1, we run a two-sample t-test at full enrollment and track the p-value and arm means across simulation replicates. This is the simplest complete rxsim workflow and a good starting point before moving to more complex designs. See Getting Started for an overview of the package.

Scenario

Capture scenario parameters. We will assume piece-wise linear enrollment.

sample_size <- 100
arms <- c("pbo", "trt")
allocation <- c(1,1)
delta <- 0.2
enrollment_fn <- function(n) rexp(n, rate = 1)
dropout_fn <- function(n) rexp(n, rate = 0.01)
scenario <- tidyr::expand_grid(
  sample_size = sample_size,
  allocation = list(allocation),
  delta = delta
)

allocation = c(1, 1) specifies balanced randomisation, equal expected numbers per arm. Using tidyr::expand_grid() to build the scenario data.frame embeds the design parameters directly into each analysis result row, making results self-documenting and easy to compare across parameter sweeps.

Populations

Define population generators.

population_generators <- list(
  pbo = function(n) data.frame(
    id = 1:n,
    value = rnorm(n),
    readout_time = 1
  ),
  trt = function(n) data.frame(
    id = 1:n,
    value = rnorm(n, delta),
    readout_time = 1
  )
)

Each population generator is a function of n that returns a data.frame with one row per subject. readout_time = 1 means the endpoint is observed exactly 1 time unit after a subject enrolls. The placebo arm has a mean of 0 and the treatment arm a mean of delta, a small-to-moderate standardised effect.

Triggers & Analysis

We want to do a t-test when sample_size subjects have been enrolled.

analysis_generators <- list(
  final = list(
    trigger = rlang::exprs(
      sum(!is.na(enroll_time)) >= !!sample_size
    ),
    analysis = function(df, timer){
      df_enrolled <- df |> subset(!is.na(enroll_time))
      tt <- t.test(value ~ arm, data = df_enrolled)
      data.frame(
        scenario,
        n_total = nrow(df_enrolled),
        mean_pbo = mean(df_enrolled$value[df_enrolled$arm == "pbo"]),
        mean_trt = mean(df_enrolled$value[df_enrolled$arm == "trt"]),
        p_value = unname(tt$p.value),
        stringsAsFactors = FALSE
      )
    }
  )
)

The trigger fires when the cumulative count of enrolled subjects (sum(!is.na(enroll_time))) reaches sample_size. Inside the analysis function, subset(!is.na(enroll_time)) drops subjects who have been allocated but not yet enrolled. rxsim pre-generates the full allocation list so filtering is essential. The two-sample t-test then compares endpoint values between the two enrolled arms.

Trial

Make multiple trial replicates.

trials <- replicate_trial(
  trial_name = "test_trial",
  sample_size = sample_size,
  arms = arms,
  allocation = allocation,
  enrollment = enrollment_fn,
  dropout = dropout_fn,
  analysis_generators = analysis_generators,
  population_generators = population_generators,
  n = 3
)

Simulate

To simulate all replicates:

run_trials(trials)
#> [[1]]
#> <Trial>
#>   Public:
#>     clone: function (deep = FALSE)
#>     conditions: list
#>     initialize: function (name, seed = NULL, timer = NULL, population = list(),
#>     locked_data: list
#>     name: test_trial_1
#>     population: list
#>     results: list
#>     run: function ()
#>     seed: NULL
#>     timer: Timer, R6
#>
#> [[2]]
#> <Trial>
#>   Public:
#>     clone: function (deep = FALSE)
#>     conditions: list
#>     initialize: function (name, seed = NULL, timer = NULL, population = list(),
#>     locked_data: list
#>     name: test_trial_2
#>     population: list
#>     results: list
#>     run: function ()
#>     seed: NULL
#>     timer: Timer, R6
#>
#> [[3]]
#> <Trial>
#>   Public:
#>     clone: function (deep = FALSE)
#>     conditions: list
#>     initialize: function (name, seed = NULL, timer = NULL, population = list(),
#>     locked_data: list
#>     name: test_trial_3
#>     population: list
#>     results: list
#>     run: function ()
#>     seed: NULL
#>     timer: Timer, R6

Bind one row per replicate into one data frame.

replicate_results <- collect_results(trials)
replicate_results
#>   replicate timepoint analysis sample_size allocation delta n_total    mean_pbo
#> 1         1  87.36847    final         100       1, 1   0.2     100 -0.02475451
#> 2         2  83.92580    final         100       1, 1   0.2     100 -0.05831826
#> 3         3  96.44952    final         100       1, 1   0.2     100 -0.25739017
#>     mean_trt    p_value
#> 1 0.32833062 0.05877739
#> 2 0.13052493 0.36397787
#> 3 0.08945477 0.09253380

collect_results() returns a data.frame with replicate, timepoint, and analysis columns prepended to your analysis columns. The p_value column varies across replicates because each replicate draws fresh random data.
